References

Installations in more than 120 countries

RAy3, 80 GHz
Linking cable car stations
High altitude
Extreme weather conditions
Challenging installation
1+1 redundancy

RipEX, RipEX2
Power distribution
160 MHz, 25 kHz, 16DEQAM
Base Driven Protocol
Reclosers, DNP3 protocol
Backup routes
LTE or 2x RS232 mPCIE modules

RipEX, 50 kHz/ 16DEQAM
RipEX2, 200 kHz/256QAM
Power distribution
Remote meter reading
Two levels backhaul
Base Driven Protocol
TCP/IP

RipEX2 with Cellular module
400 MHz, 25 kHz, D8PSK – 256QAM
Modbus TCP
Flexible protocol, up to 6 repeaters
Report by exception
Sleep mode
Solar powering

RipEX2, 400 MHz
DMR Tier 3
Voice Network
Base station interconnection
Full duplex p-t-p links
50 kHz channel, 64 QAM, 250 kbps
Mountain area, NLOS

RAy3, 18 GHz
WISP in New Zealand
Rural areas
Challenging conditions
Backhaul links
Long distances, 1 Gb/s

RipEX2, 400 MHz
Power distribution
Full duplex p-t-p links
1.6 Mbps
99,9% availibility
19‘ rack installation
Rio de Janeiro

RAy3, 24 GHz
WISP in NYC
Crowded area
Interference tolerant
Backhaul link
Manhattan to Bronx
4 km, 1 Gb/s

RipEX, RipEX-HS, 400 MHz
Wellhead monitoring
Hazardous location
Base Driven Protocol
Modbus TCP
Solar powered
Siemens RTUs

RipEX, 400 MHz
Tanker loading
Marine environment
DNP3 protocol
Point to multipoint
Siemens RTU
Maximum reliability

RipEX, RipEX2
Water Management
Migration Solution
Multiple Repeaters
Custom protocol, Modbus TCP, TCP/IP
Opto 22 EPIC / Allen Bradley ControlLogix

RAy3
Backhaul and Last Mile
Systems Integrator / ISP
Corporates and private
Resistance to Interference
High reliability

RipEX2, 400 MHz
Water Management
Migration solution
16 DEQAM modulation
25 kHz channel
Up to four Repeaters
Two Control centres

RipEX2, 150 MHz
Underground
Leaky Feeder
256QAM
Point to Multipoint

M!DGE
Leak detection System
Open VPN
Customized Software
Modbus TCP protocol
Marine environment

RipEX, 300 MHz
Environmental Monitoring
Installation on sea buoys
Solar powered
Flexible protocol
Maximum reliability
Multiple repeaters

RipEX, 400 MHz
M!DGE
Water Management
Hybrid network
Flexible protocol
Back up routes
Fully redundant data centres

Cableways security
France
RipEX, 160 MHz
Flexible protocol
Czechia
RipEX2, 400 MHz
Base driven protocol

RipEX, 400 MHz
Overhead transport management
Moving Installation
TCP/IP
Base Driven Protocol
FEC
Flexible rod antennas

RipEX2, RipEX2-HS
Power and Water Distribution
Base driven protocol
DNP3
Ongoing migration
DPSK to 256 QAM
25 kHz bandwidth

RipEX, RipEX-HS, 400 MHz
Power distribution
Extreme reliability requirements
IEC 104 – Base driven protocol
Bespoke cabinets made by RACOM
Siemens Ruggedcom switches
ABB RTU’s

RipEX 160 MHz
Water Management
Solar powered
Flexible protocol
Back up routes, Repeaters
Ongoing Migration
4CPFSK modulation

RAy, 10,11 & 17 GHz
Government services
Backhaul links
B2G – Business to Government services
Equatorial conditions
Excellent Stability & Reliability
Long links – 24 Km

RipEX 400 MHz
Split time transmissions
Online TV broadcasting
Three locations, Multiple hops
Flexible protocol
Highest possible reliability
25 kHz, 4CPFSK

RipEX 400
Power Distribution
Bridge mode
Recloser Management
25 km average link length
Easy setup & management
Remote rural area

RipEX, 450 MHz
Mountain Rescue service
PMR voice system
Base to Base backhaul
50kHz channel, 16 DEQAM, 140 kbps
Mountainous Region
PtP Robust NLOS

Ripex, 400 MHz
Water utility
Migration Solution
No additional migration hw
Both networks concurrently
One frequency for both networks
150 sites in the 1 st stage

M!DGE
Power Distribution
Ethernet and Serial Interface
Cisco, Vigor… in the centre
Sub-tropical climate
IEC101 and IEC104
Over 1000 remotes

RAy, 11 GHz
National Emergency system
Fibre backup
Two-way mobile backbone
Government centres connectivity
Exceptional reliability
Ease of installation

RAy, 17, 18 & 24 GHz
Service provider in Ireland
Backhaul & Last mile
Corporates & Private
100 links by 2017
Easy configuration
Resistance to disturbances

M!DGE
Leased services network
Mission critical applications
Ethernet and serial interface
Mountainous arctic environment
Extreme temperatures up to -30 °C
Over 500 units deployed

M!DGE
Power distribution
Fault indicators
Reclosers
Tropical environment
Serial & Ethernet
Over 100 units by 2017

M!DGE
Oil & Gas
Wellhead monitoring
Desert environment, +50 oC
Mission critical application
Installed with outdoor antenna
Integrated with Rockwell RTUs

RAy, 11 GHz
Air traffic control
Desert environment, +50 oC
Long haul link, 18 km
90 cm antennas
-65dB RSSI recorded
No downtime from 2015

M!DGE
ATM banking system
Installation in ‘war zone’
Desert environment, +50 oC
Over 100 sites and growing
Security and reliability

RAy, 24 GHz
WISP in Hungary
Long-haul links
Full speed even over 10 km
Exceptional system gain
68 cm antennas
Full outdoor

RipEX, 400 MHz
Power distribution
Pole top circuit breakers
DNP3 for SCADA
COM1 and COM2 concurrently
High speed / 16DEQAM
50 remotes under one base station

RipEX, 400 MHz
Water distribution
Migration from legacy network
Robustness, Reliability, Flexibility
SIEMENS S7-1200 RTU’s
Direct remote-to-remote communication
More than 50 sites

RipEX 300 MHz & M!DGE
Hybrid network
Power distribution
Tropical environment
Up to four repeating hops
Multi-master
IEC101, IEC104 and DNP3

RAy, 24 GHz
Biggest WISP in Hungary
Migration from 5 GHz to 24 GHz
Link length up to 10 km
Low consumption
Easy setup & management
Long warranty

RipEX, 400 MHz
Water well management
Installation in desert, over +50 °C
High reliability
Long distances – 10W
Modbus protocol
One Master & 64 remotes

RAy, 10 & 24 GHz
Traffic flow monitoring
Videos from routes to control room
Repeaters on the way
Resistance to interference
60 links in Prague
Case study

RipEX, 400 MHz
Online TV broadcasting
TV motorized camera control
Ground to Air
Joystick to Camera
Mass radio interference
50 kHz channel, π/4DQPSK, 69 kbps

RipEX, RipEX-HS, 432 MHz
Irrigation & Security management
Two control centers
Flexible protocol
Solar powering – Sleep mode
Back up routes
Over 100 remote sites

RipEX, 400 MHz
Water distribution
Modbus TCP
Autospeed functionality
TCP proxy
AES256 encryption
PtP and PtMP, Robust NLOS

RipEX, 400 MHz & RAy, 10 GHz
Traffic flow management
RAy for backbone to base stations
Sleep and Save modes
Mixed TCP and UDP
Polling and Report-by-exception
Over 100 remote sites

MR400, 160 MHz, Integrated GPS
Train fleet & crossing zones management
Remote desert installation, +50 °C
Multiple Ethernet and Serial applicatons
Mobile roaming protocol on Radio channel
180 km single track railway
3 repeaters for inclusive coverage

RipEX, 400 MHz & M!DGE
Emergency Early Warning System
M!DGE used for backup
MQTT protocol for sirens
Mesh Network
Backup routes
14 sites in 9 cities

RAy, 11 GHz
WISP in Beirut
Extreme Middle East climatic conditions
Migration from 5 GHz to 11 GHz
Backhaul & Last mile
Receiver robustness = smaller antennas
Exceptional stability

RipEX, 400 MHz
Installed in electric aircraft
Air to Air
Air to Ground
Real time data transfer
35 km air-to-air, 10 cm antennas
Crossing English Channel

RipEX, 400 MHz
Water monitoring at wellheads
Remote desert installations, +50 °C
Serial interface
Siemens ‘WinCC’ SCADA and ’S7-300’ PLC
Bridge mode
2 base stations and over 20 remotes

RAy, 10, 17 & 24 GHz
Global Telco operator
Corporate last-mile solution
Hundreds of links
Exceptional reliability
Remote diagnostics and monitoring
=> No maintenance cost

RipEX, RipEX-HS, 400 MHz
Water distribution
Whole Malta, 300 units
Modbus TCP & Ethernet/IP
Two independent SCADA applications
Back up routes

RipEX, 160 MHz
Power distribution
Extreme Middle East climatic conditions
DNP3 protocol
Backup routes, Multi repeaters
Press release
5000 sites planned

M!DGE
Power distribution
Desert environment, +50 °C
IPsec
IEC 104
More than 150 sites and growing

RAy, 10, 17 & 24 GHz
Infrastructe for Telco operators
Used in O2 network
Corporate last-mile solution
Backhaul for DSLAM connections
Approx. 4000 links

RipEX, RipEX-HS, 400 MHz
Power distribution
Siemens and ABB RTU’s
RP-570, IEC101, IEC104
AES 256 encryption
Backup routes
Over 100 sites

RipEX, RipEX-HS, 400 MHz
Power distribution
Mass interference on pole mountings
Underground installations
2 COM’s with DNP3 concurrently on remotes
Over 10.000 remote sites

RAy, 10, 17, 18 & 24 GHz
TV and Internet provider
Backbone
High speed last mile
B2B Services
More than 100 links
High performance while excellent stability

Currently RipEX, 400 MHz
Different Radio modems
Since 1995
Special usage
Fixed and mobile networks
Multi-master polling & report-by-exception
Over 4000 units till 2017

MR400, 400 MHz
Train fleet management
SCADA, tracking, messaging
Above and below ground level
IP backbone to base stations
RANEC
100 trains, 25 base stations

MR400, 400 MHz
Avalanche protection
Hydrometric services
Solar powering – Sleep mode
Temperatures below -30 °C
Altitude up to 3400 m
7500 km², 100 units

MR400, 400 MHz
Water distribution
Multiple applications
Siemens Simatic 7, Siemens 95U
MARS-A, Siemens 3964R protocols
Polling & Report-by-exception
1 simplex 25 kHz channel, over 100 sites
